Command codes
M24LR04E-R
94/142
Doc ID 022208 Rev 5
Response parameter:
●
Error code as Error_flag is set
–
11h: the specified block is already locked and thus cannot be locked again
–
14h: the specified block was not successfully locked
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Lock AFI command to the end of the M24LR04E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin is tied to 0 for the
entire duration of the internal write cycle (from the end of valid Lock AFI command to the
beginning of the M24LR04E-R response).
Table 62.
Lock AFI response format when Error_flag is set
Response
SOF
Response_flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 62.
Lock AFI frame exchange between VCD and M24LR04E-R
VCD
SOF
Lock AFI
request
EOF
M24LR04E-R
<-t1-> SOF
Lock AFI
response
EOF
Lock sequence
when error
M24LR04E-R
<----------------- Wt -----------> SOF
Lock AFI
response
EOF
