90 / 142 page  Command codes M24LR04E-R 90/142 Doc ID 022208 Rev 5 Response parameter: ● No parameter Response parameter: ● Error code as Error_flag is set: – 03h: the option is not supported When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that starts the Select command to the end of the M24LR04E-R response. When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z state. Table 53. Select response format when Error_flag is set Response SOF Response_ flags Error code CRC16 Response EOF 8 bits 8 bits 16 bits Figure 59. Select frame exchange between VCD and M24LR04E-R VCD SOF Select request EOF M24LR04E-R <-t1-> SOF Select response EOF |
|
