www.ittcannon.com

Dimensions shown in inches (mm)

Specifications and dimensions subject to change

C

C-19

Cannon 90° PCB, High Density Plug

Military/High Reliability D-Subminiature

90° High Density Plug PC Tail with Plastic Bracket

Shell Size

Layout

Through Hole

with bracket

DE

15

DEMA15PL

DA

26

DAMA26PL

DB

44

DBMA44PL

DC

62

DCMA62PL

DD

78

DDMA78PL

DF

104

DFMA104PLF216

Plug

Note: For Residual Magnetism Level of 200 gamma, add NMBK52. Example DEMA15PLNMBK52

contacts and shells have 50 microinches gold. Shown with bracket, for version without bracket,

use termination modifier "P". "F" size shells use machined aluminum shells only.

Shell

A

B

C

D

E

F

W

W

K

M

N

size ± 0,38 (.015) ± 0,13 (.005) ± 0,13 (.005) ± 0,13 (.005) ± 0,38 (.015) ± 0,25 (.010) ± 0,368 (.0145) ± 0,41 (.016) ± 0,317 (.0125) ± 0,25 (.010) ± 0,25 (.010)

DE

30,81 (1.213)

16,92 (.666)

24,99 (8,36)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

0,76 (.030)

18,901 (.740)

13,82 (.544)

DA

39,14 (1.541)

25,25 (.994)

33,32 (1.312)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

0,76 (.030)

18,901 (.740)

13,82 (.544)

DB

53,04 (2.088)

38,96 (1.534)

47,04 (1.852)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

18,901 (.740)

13,82 (.544)

DC

69,32 (2.729)

55,42 (2.182)

63,50 (2.500)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

18,901 (.740)

13,82 (.544)

DD

66,93 (2.635)

52,81 (2.079)

61,11 (2.406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

-

6.84 (.269)

0,76 (.030)

20,07 (.790)

15,39 (.606)

DF

69,32 (2.729)

56,69 (2.232)

63,50 (2.500)

13,23 (.521)

16,97 (.668)

10,90 (.429)

-

6,94 (.273)

0,76 (.030)

22,14 (.872)

15.60 (.614)

0,51 (.020) O

O 3,05

(.120)

4,01

0,69

.150

L

± .020

±

1.98

,17

(.078 .007)

±

±

3,96

,17

(.078 .007)

±

±

11,68 (max)

(.460)

Size D
