Cannon Crimp, Size 22

Military/High Reliability

D*MA High Density Crimp Contact Cable Connector

Note: For Residual Magnetism Level of 200 gamma, add B. Example DEMA15PNMB

For shells with 50 microinches gold, add K52. Example: DEMA15PNMBK52.

For connectors without contacts, add F0. Example: DEMA15PF0 (F0 not marked on

connector)

For crimp (Size 22) contacts and tooling, see page C-7.

Dimensions

Shell

A

B

C

D

E

F

W

K

L

size

± 0,38 (.015)

± 0,13 (.005)

± 0,13 (.005)

± 0,13 (.005)

± 0,38 (.015)

± 0,25 (.010)

± 0,368 (.0145) ± 0,317 (.0125) ± 0,25 (.010)

DE

30,81 (1.213)

16,33 (.643)

24,99 (8,36)

7,90 (.311)

12,55 (.494)

10,90 (.429)

6,94 (.273)

1,206 (.0475)

0,76 (.030)

DA

39,14 (1.541)

24,66 (.971)

33,32 (1.312)

7,90 (.311)

12,55 (.494)

10,90 (.429)

6,94 (.273)

1,206 (.0475)

0,76 (.030)

DB

53,04 (2.088)

38,38 (1.511)

47,04 (1.852)

7,90 (.311)

12,55 (.494)

10,90 (.429)

6,94 (.273)

1,206 (.0475)

0,76 (.030)

DC

69,32 (2.729)

54,84 (2.159)

63,50 (2.500)

7,90 (.311)

12,55 (.494)

10,90 (.429)

6,94 (.273)

1,206 (.0475)

0,76 (.030)

DD

66,93 (2.635)

52,42 (2.064)

61,11 (2.406)

10,74 (.423)

15,37 (.605)

10,90 (.429)

6,94 (.273)

1,206 (.0475)

0,76 (.030)

Engaging Face

A

C

B

10°

E

D

Ø 3,05 (.120)

8,76 (.345) MAX

L

K

F

W

Receptacle

Note: For residual magnetism level of 200 Gamma and shells and contacts with

50 micro inches (1,27m) gold plating, add NMBK52. Example DEMA15SNMBK52

contacts and shells with 50 microinches gold. For connectors without contacts, add F0.

Example: DEMA15SF0 (F0 not marked on the connector). For crimp (Size 22) contacts

and tooling, see page C-13.

Dual

Shell Size

Layout

Through Hole

Float Mount

DE

15

DEMA15S

DEMAY15S

DA

26

DAMA26S

DAMAY26S

DB

44

DBMA44S

DBMAY44S

DC

62

DCMA62S

DCMAY62S

DD

78

DDMA78S

DDMAY78S

DF

104

DFMA104SF216

DFMA41045F216

Dimensions

Shell

A

B

C

D

E

F

W

W

K

K

L

size ± 0,38 (.015) ± 0,13 (.005) ± 0,13 (.005) ± 0,13 (.005) ± 0,38 (.015) ± 0,25 (.010) ± 0,368 (.0145) ± 0,41 (.016) ± 0,317 (.0125) ± 0,25 (.010) ± 0,25

(.010)

DE

30,81 (1.213)

16,92 (.666)

24,99 (.984)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

1,206 (.0475)

-

0,76 (.030)

DA

39,14 (1.541)

25,25 (.994)

33,32 (1.312)

8,36 (.329)

12,55 (.494)

10,72 (.422)

6,693 (.2635)

-

1,206 (.0475)

-

0,76 (.030)

DB

53,04 (2.088)

38,96 (1.534)

47,04 (1.852)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

-

1,52 (.060)

0,99 (.039)

DC

69,32 (2.729)

55,42 (2.182)

63,50 (2.500)

8,36 (.329)

12,55 (.494)

10,82 (.426)

-

6.84 (.269)

-

1,52 (.060)

0,99 (.039)

DD

66,93 (2.635)

52,81 (2.079)

61,11 (2.406)

11,07 (.436)

15,37 (.605)

10,82 (.426)

-

6.84 (.269)

-

1,52 (.060)

0,99 (.039)

DF (see Space Catalog)

Engaging Face

A

C

B

10°

E

D

Ø 3,05 (.120)

8,76 (.345) MAX

F

W

L

K

Plug

Shell Size

Layout

Dual

Through Hole

Float Mount

DE

15

DEMA15P

DEMAY15P

DA

26

DAMA26P

DAMAY26P

DB

44

DBMA44P

DBMAY44P

DC

62

DCMA62P

DCMAY62P

DD

78

DDMA78P

DDMAY78P

DF

104

DFMA104PF216

DFMA4104PF216
