CC1150-RTY1 datasheet(5/67 Pages) TI

5 / 67 page

CC1150

SWRS037A

Page 5 of 60

Absolute Maximum Ratings

Under no circumstances must the absolute maximum ratings given in Table 1 be violated. Stress

exceeding one or more of the limiting values may cause permanent damage to the device.

Caution!

ESD

sensitive

device.

Precaution should be used when handling

the device in order to prevent permanent

damage.

Parameter

Min

Max

Units

Condition

Supply voltage

–0.3

3.6

All supply pins must have the same voltage

Voltage on any digital pin

–0.3

VDD+0.3

max 3.6

Voltage on the pins RF_P, RF_N

and DCOUPL

–0.3

2.0

Voltage ramp-up

120

kV/µs

Input RF level

+10

dBm

Storage temperature range

–50

150

°C

Solder reflow temperature

260

°C

According to IPC/JEDEC J-STD-020C

ESD

<500

According to JEDEC STD 22, method A114,

Human Body Model

Table 1: Absolute Maximum Ratings

Operating Conditions

The operating conditions for

CC1150 are listed Table 2 in below.

Parameter

Min

Max

Unit

Condition

Operating temperature

-40

°C

Operating supply voltage

1.8

3.6

All supply pins must have the same voltage

Table 2: Operating Conditions

General Characteristics

Parameter

Min

Typ

Max

Unit

Condition/Note

300

348

MHz

400

464

MHz

Frequency range

800

928

MHz

Data rate

1.2

500

250

500

kBaud

2-FSK

GFSK, OOK and ASK

(Shaped) MSK (also known as differential offset

QPSK)

Optional Manchester encoding (the data rate in kbps

will be half the baud rate)

Table 3: General Characteristics
