DocID4997 Rev 13

7/33

M93C86xx M93C76xx M93C66xx M93C56xx M93C46xx

Description

Figure 2. 8-pin package connections (top view)

1. See Section 11: Package mechanical data for package dimensions, and how to identify pin-1.

2. DU = Don’t Use. The DU (do not use) pin does not contribute to the normal operation of the device. It is

reserved for use by STMicroelectronics during test sequences. The pin may be left unconnected or may be

Table 3. Signal names

Signal name

Function

Direction

S

Chip Select

Input

D

Serial Data input

Input

Q

Serial Data output

Output

C

Serial Clock

Input

ORG

Organization Select

Input

Supply voltage

Ground

VSS

Q

ORG

DU

C

SVCC

D

AI01929B

M93Cx6

1

2

3

4

8

7

6

5
