DC and AC parameters

M93C86xx M93C76xx M93C66xx M93C56xx M93C46xx

20/33

DocID4997 Rev 13

10

DC and AC parameters

This section summarizes the operating and measurement conditions, and the dc and ac

characteristics of the device. The parameters in the dc and ac characteristic tables that

follow are derived from tests performed under the measurement conditions summarized in

the relevant tables. Designers should check that the operating conditions in their circuit

match the measurement conditions when relying on the quoted parameters.

Table 8. Operating conditions (M93Cx6)

Symbol

Parameter

Min.

Max.

Unit

Supply voltage

4.5

5.5

V

Ambient operating temperature

–40

85

°C

Table 9. Operating conditions (M93Cx6-W)

Symbol

Parameter

Min.

Max.

Unit

Supply voltage

2.5

5.5

V

Ambient operating temperature

–40

85

°C

Table 10. Operating conditions (M93Cx6-R)

Symbol

Parameter

Min.

Max.

Unit

Supply voltage

1.8

5.5

V

Ambient operating temperature

–40

85

°C

Table 11. AC measurement conditions (M93Cx6)

Symbol

Parameter

Min.

Max.

Unit

Load capacitance

100

pF

Input rise and fall times

50

ns

Input voltage levels

0.4 V to 2.4 V

V

Input timing reference voltages

1.0 V and 2.0 V

V

Output timing reference voltages

0.8 V and 2.0 V

V

Table 12. AC measurement conditions (M93Cx6-W and M93Cx6-R)

Symbol

Parameter

Min.

Max.

Unit

Load capacitance

100

pF

Input rise and fall times

50

ns

Input voltage levels

V

Input timing reference voltages

V

Output timing reference voltages

V
