EM260
120-0260-000M Rev 1.1
Page 34
22. Stop transmitting after the number of bytes (length) is received plus the Frame Terminator.
23. Decode the response:
0xFE
: SPI Byte indicating an EZSP Frame
0x04
: Length Byte showing the EZSP Frame is 3 bytes long
0x00
: EZSP Sequence Byte (Note that this value should vary based upon previous sequence bytes)
0x80
: EZSP Frame Control Byte indicating a response with no overflow
0x19
: EZSP Frame ID Byte indicating the stackStatusHandler command
0x91
: EZSP Parameter for this response (EmberStatus EMBER_NETWORK_DOWN)
0xA7
– Frame Terminator
24. Deactivate Slave Select.
25. Since nHOST_INT does not assert again, there is no more data for the Host.
