EM260
Page 11
120-0260-000M Rev 1.1
3.4
DC Electrical Characteristics
Table 5 lists the DC electrical characteristics of the EM260.
Note: Current measurements were collected using the EmberZNet software stack Version 3.0.1.
Table 5. DC Characteristics
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
Regulator input voltage (VDD_PADS)
2.1
3.6
V
Power supply range (VDD_CORE)
1.7
1.8
1.9
V
Deep Sleep Current
Quiescent current, including internal
RC oscillator
At 25° C
1.0
A
RESET Current
Quiescent current, nRESET asserted
Typ at 25° C/3V
Max at 85° C/3.6V
1.5
2.0
mA
RX Current
Radio receiver, MAC, and baseband
(boost mode)
30.0
mA
Radio receiver, MAC, and baseband
28.0
mA
CPU, RAM, and Flash memory
At 25° C and 1.8V core
8.0
mA
Total RX current
( = IRadio receiver, MAC and baseband, CPU +
IRAM, and Flash memory )
At 25° C, VDD_PADS = 3.0V
36.0
mA
TX Current
Radio transmitter, MAC, and baseband
(boost mode)
At max. TX power (+ 5dBm
typical)
34.0
mA
Radio transmitter, MAC, and baseband
At max. TX power (+ 3dBm
typical)
28.0
mA
At 0 dBm typical
24.0
mA
At min. TX power (- 32dBm
typical)
19.0
mA
CPU, RAM, and Flash memory
At 25° C, VDD_PADS = 3.0V
8.0
mA
Total TX current
( = IRadio transmitter, MAC and baseband, CPU +
IRAM, and Flash memory )
At 25° C and 1.8V core; max.
power out
36.0
mA
