47 / 64 page  E5EZ-PRR 47 Setting the Input Type The Controller supports four input types: platinum resistance thermometer, thermocouple, infrared temperature sensor, and analog inputs. Set the input type that matches the sensor that is used. In the product specifications, there are models with thermocouple/resistance thermometer inputs (universal input) and models with analog input. The settings differ depending on the model. Check to make sure which model you are using. List of Input Types The default is "5" The default is "0" Input Type Specifications Set value Input temperature setting range Platinum Resistance Thermometer Pt100 0 −200 to 850 (°C) / −300 to 1500 (°F) 1 −199.9 to 500.0 (°C) / −199.9 to 900.0 (°F) 2 0.0 to 100.0 (°C) / 0.0 to 210.0 (°F) JPt100 3 −199.9 to 500.0 (°C) / −199.9 to 900.0 (°F) 4 0.0 to 100.0 (°C) / 0.0 to 210.0 (°F) Thermocouple K 5 −200 to 1300 (°C) / −300 to 2300 (°F) 6 −20.0 to 500.0 (°C) / 0.0 to 900.0 (°F) J 7 −100 to 850 (°C) / −100 to 1500 (°F) 8 −20.0 to 400.0 (°C) / 0.0 to 750.0 (°F) T 9 −200 to 400 (°C) / −300 to 700 (°F) 22 −199.9 to 400.0 (°C) / −199.9 to 700.0 (°F) E 10 0 to 600 (°C) / 0 to 1100 (°F) L11 −100 to 850 (°C) / −100 to 1500 (°F) U 12 −200 to 400 (°C) / −300 to 700 (°F) 23 −199.9 to 400.0 (°C) / −199.9 to 700.0 (°F) N13 −200 to 1300 (°C) / −300 to 2300 (°F) R 14 0 to 1700 (°C) / 0 to 3000 (°F) S 15 0 to 1700 (°C) / 0 to 3000 (°F) B 16 100 to 1800 (°C) / 300 to 3200 (°F) Infrared temperature sensor, ES1B 10°C to 70°C 17 0 to 90 (°C) / 0 to 190 (°F) 60°C to 120°C 18 0 to 120 (°C) / 0 to 240 (°F) 115°C to 165°C 19 0 to 165 (°C) / 0 to 320 (°F) 140°C to 260°C 20 0 to 260 (°C) / 0 to 500 (°F) Analog Input 0 to 50 mV 21 Either of the following ranges, by scaling: −1999 to 9999 or −199.9 to 999.9 Input Type Specifications Set value Input temperature setting range Analog Input Type Current Input 4 to 20 mA 0 Use the following scales based on the range of measurements: −1999 to 9999 −199.9 to 999.9 −19.99 to 99.99 −1.999 to 9.999 0 to 20 mA 1 Voltage Input 1 to 5 V 2 0 to 5 V 3 0 to 10 V 4 in-t 5 l.ini Input Types 5 |
|
