IS25LP256
Integrated Silicon Solution, Inc.- www.issi.com
11
Rev.00A
1/16/2014
PACKAGE TYPE INFORMATION
8-CONTACT ULTRA-THIN SMALL OUTLINE NO-LEAD (WSON) PACKAGE 8X6MM (JL)
.
Note: All dimensions are in millimeters.
SYMBOL
DIMENSION IN MM
MIN.
NOM
MAX
A
0.70
0.75
0.80
A1
0.00
0.02
0.05
A2
- - -
0.20
- - -
D
7.90
8.00
8.10
E
5.90
6.00
6.10
D1
4.65
4.70
4.75
E1
4.55
4.60
4.65
e
- - -
1.27
- - -
b
0.35
0.40
0.48
L
0.4
0.50
0.60
ADVANCED INFORMATION
