CC1100
SWRS038D
Page 22 of 92
8
Configuration Overview
CC1100 can be configured to achieve optimum
performance for many different applications.
Configuration is done using the SPI interface.
The
following
key
parameters
can
be
programmed:
•
Power-down / power up mode
•
Crystal oscillator power-up / power-down
•
Receive / transmit mode
•
RF channel selection
•
Data rate
•
Modulation format
•
RX channel filter bandwidth
•
RF output power
•
Data buffering with separate 64-byte
receive and transmit FIFOs
•
Packet radio hardware support
•
Forward Error Correction (FEC) with
interleaving
•
Data Whitening
•
Wake-On-Radio (WOR)
Details of each configuration register can be
found in Section 33, starting on page 60.
Figure 5 shows a simplified state diagram that
explains the main
CC1100 states, together with
typical usage and current consumption. For
detailed information on controlling the
CC1100
state machine, and a complete state diagram,
see Section 19, starting on page 42.
