CC1100
SWRS038D
Page 51 of 92
Output Power [dBm]
PATABLE Setting
315 MHz
433 MHz
868 MHz
915 MHz
0x00
-62.0
-62.0
-57.1
-56.0
0x30
-41.7
-39.0
-33.6
-33.1
0x31
-21.8
-21.7
-21.2
-21.0
0x32
-16.2
-16.1
-16.0
-15.8
0x33
-12.8
-12.7
-12.7
-12.5
0x34
-10.5
-10.4
-10.5
-10.3
0x35
-8.6
-8.5
-8.7
-8.5
0x36
-7.2
-7.1
-7.4
-7.2
0x37
-5.9
-5.8
-6.2
-6.0
0x38
-4.8
-4.9
-5.3
-5.1
0x39
-3.9
-4.0
-4.5
-4.3
0x3A
-3.2
-3.3
-3.8
-3.7
0x3B
-2.5
-2.7
-3.3
-3.1
0x3C
-2.1
-2.3
-2.8
-2.7
0x3D
-1.7
-1.9
-2.5
-2.3
0x3E
-1.3
-1.6
-2.1
-2.0
0x3F
-1.1
-1.3
-1.9
-1.7
Table 32: PATABLE Settings used together with ASK Shaping and PA Ramping
Assume working in the 433 MHz and using
FSK. The desired output power is -10 dBm.
Figure 24 shows how the PATABLE should
look like in the two cases where no ramping is
used (A) and when PA ramping is being
implemented (B). In case A, the PATABLE
value is taken from Table 30, while in case B,
the values are taken from Table 32.
PATABLE[7] = 0x00
PATABLE[6] = 0x00
PATABLE[5] = 0x00
PATABLE[4] = 0x00
PATABLE[3] = 0x00
PATABLE[2] = 0x00
PATABLE[1] = 0x00
PATABLE[0] = 0x26
FREND0.PA_POWER = 0
PATABLE[7] = 0x00
PATABLE[6] = 0x00
PATABLE[5] = 0x34
PATABLE[4] = 0x33
PATABLE[3] = 0x32
PATABLE[2] = 0x31
PATABLE[1] = 0x30
PATABLE[0] = 0x00
FREND0.PA_POWER = 5
A: Output Power = -10 dBm,
No PA Ramping
B: Output Power = -10 dBm,
PA Ramping
Figure 24: PA Ramping
