HOLD timing

HOLD is an asynchronous input that can be asserted at any time during a clock cycle. If the specified timings are met, the exact sequence

shown in Figure 27 occurs; otherwise, an additional delay of one clock cycle is possible.

The table, “timing parameters for HOLD / HOLDA”, defines the timing parameters for the HOLD and HOLDA signals. The numbers shown in

Figure 27 correspond with those in the NO. column of the table.

The NOHOLD bit of the primary-bus control register overrides the HOLD signal. When this bit is set, the device comes out of hold and prevents

future hold cycles.

Asserting HOLD prevents the processor from accessing the primary bus. Program execution continues until a read from or a write to the

primary bus is requested. In certain circumstances, the first write is pending, thus allowing the processor to continue until a second write is

encountered.

timing parameters for HOLD/HOLDA (see Figure 27)

NO.

’LC31-33

’C31-40

’LC31-40

’C31-50

’C31-60

’C31-80

UNIT

MIN

MAX

MIN

MAX

MIN

MAX

MIN

MAX

MIN

MAX

69

tsu(HOLD-H1L)

Setup time, HOLD before H1 low

15

13

10

8

5

ns

70

tv(H1L-HOLDA)

Valid time, HOLDA after H1 low

0†

10

0†

9

0†

7

0†

6

0†

5

ns

71

tw(HOLD)‡

Pulse duration, HOLD low

2tc(H)

2tc(H)

2tc(H)

2tc(H)

2tc(H)

ns

72

tw(HOLDA)

Pulse duration, HOLDA low

tcH–5†

tcH–5†

tcH –5†

tcH –5†

tcH–5†

ns

73

td(H1L-SH)H

Delay time, H1 low to STRB high for a HOLD

0§

10

0§

9

0§

7

0§

6

0§

4

ns

74

tdis(H1L-S)

Disable time, H1 low to STRB to the

high-impedance state

0§

10†

0§

9†

0§

8†

0§

7†

0§

7†

ns

75

ten(H1L-S)

Enable time, H1 low to STRB enabled (active)

0§

10

0§

9

0§

7

0§

6

0§

6

ns

76

tdis(H1L-RW)

Disable time, H1 low to R/W to the

high-impedance state

0†

10†

0†

9†

0†

8†

0†

7†

0†

6†

ns

77

ten(H1L-RW)

Enable time, H1 low to R/W enabled (active)

0†

10

0†

9

0†

7

0†

6

0†

6

ns

78

tdis(H1L-A)

Disable time, H1 low to address to the

high-impedance state

0§

10†

0§

10†

0§

8†

0§

7†

0§

7†

ns

79

ten(H1L-A)

Enable time, H1 low to address enabled (valid)

0§

15

0§

13

0§

12

0§

11

0§

10

ns

80

tdis(H1H-D)

Disable time, H1 high to data to the

high-impedance state

0§

10†

0§

9†

0§

8†

0§

7†

0§

6†

ns

† This value is characterized but not tested

‡ HOLD is an asynchronous input and can be asserted at any point during a clock cycle. If the specified timings are met, the exact sequence shown in Figure 27 occurs; otherwise,

an additional delay of one clock cycle is possible.

§ Not tested
