AD8251
Rev. B | Page 14 of 24
25mV/DIV
2µs/DIV
Figure 42. Small Signal Response,
G = 2, RL = 2 kΩ, CL = 100 pF
25mV/DIV
2µs/DIV
Figure 43. Small Signal Response,
G = 4, RL = 2 kΩ, CL = 100 pF
25mV/DIV
2µs/DIV
Figure 44. Small Signal Response,
G = 8, RL = 2 kΩ, CL = 100 pF
1200
0
22
STEP SIZE (V)
0
1000
800
600
400
200
4
6
8
1012141618
SETTLED TO 0.01%
SETTLED TO 0.001%
Figure 45. Settling Time vs. Step Size, G = 1, RL = 10 kΩ
1200
0
22
STEP SIZE (V)
0
1000
800
600
400
200
4
6
8
101214
1618
SETTLED TO 0.01%
SETTLED TO 0.001%
Figure 46. Settling Time vs. Step Size, G = 2, RL = 10 kΩ
1200
0
22
STEP SIZE (V)
0
1000
800
600
400
200
4
6
8
101214
1618
SETTLED TO 0.01%
SETTLED TO 0.001%
Figure 47. Settling Time vs. Step Size, G = 4, RL = 10 kΩ
