DocID023426 Rev 3
13/75
LSM330
Block diagram and pin description
75
10
INT1_G
Gyroscope interrupt signal
11
INT1_A
Accelerometer interrupt1 signal
12
INT2_A
Accelerometer interrupt2 signal
13
DEN_G
Gyroscope Data Enable
14
Res
Reserved. Connect to GND
15
Res
Reserved. Connect to GND
16
Res
Reserved. Connect to GND
17
Res
Reserved. Connect to GND
18
Res
Reserved. Connect to GND
19
GND
0 V supply
20
GND
0 V supply
21
CAP
Connect to GND with ceramic capacitor(2)
22
Vdd(3)
Power supply
23
Vdd(3)
Power supply
24
Vdd(3)
Power supply
1. 100 nF filter capacitor recommended.
2. 10 nF (+/- 10%), 25 V. 1nF minimum value has to be guaranteed under 11 V bias condition1.
3. 100 nF plus 10 μF capacitors recommended.
Table 2. Pin description (continued)
Pin #
Name
Function
