SSM3515

Data Sheet

Rev. A| Page 32 of 41

Bits

Bit Name

Settings

Description

Reset

Access

[2:0]

DAC_FS

DAC Sample Rate Selection.

0x2

R/W

000

8 kHz to 12 kHz Sample Rate.

001

16 kHz to 24 kHz Sample Rate.

010

32 kHz to 48 kHz Sample Rate.

011

64 kHz to 96 kHz Sample Rate.

100

128 kHz to 192 kHz Sample Rate.

101

48 kHz to 72 kHz Sample Rate.

110

Reserved.

111

Reserved.

DAC VOLUMECONTROL REGISTER

Address: 0x03, Reset: 0x40, Name: DAC Volume Control

Table 24. Bit Descriptions for DAC Volume Control

Bits

Bit Name

Settings

Description

Reset

Access

[7:0]

VOL

Volume Control.

0x40

R/W

00000000

+24 dB.

00000001

+23.625 dB.

00000010

+23.35 dB.

00000011

+22.875 dB.

00000100

+22.5 dB.

00000101

...

00111111

+0.375 dB.

01000000

01000001

−0.375 dB.

01000010

...

11111101

−70.875 dB.

11111110

−71.25 dB.

11111111

Mute.

[7:0] VOL (R/W)

Volume Control

00000000: +24 dB.

00000001: +23.625 dB.

00000010: +23.35 dB.

...

11111101: -70.875 dB.

11111110: -71.25 dB.

11111111: Mute.
