SSM3515
Data Sheet
Rev. A| Page 34 of 41
SAI CONTROL 2 REGISTER
Address: 0x05, Reset: 0x00, Name: SAI Control 2
Table 26. Bit Descriptions for SAI Control 2
Bits
Bit Name
Settings
Description
Reset
Access
7
DATA_WIDTH
Audio Data Width.
0x0
R/W
0
Audio Input on SDATA is 24 Bits.
1
Audio Input on SDATA is 16 Bits.
[6:5]
RESERVED
Reserved.
0x0
R/W
4
AUTO_SLOT
Automatic TDM Slot Selection.
0x0
R/W
0
TDM Slot Determined by the TDM_SLOT Register.
1
TDM Slot Determined by the ADDR Pin.
[3:0]
TDM_SLOT
TDM Slot Selection.
0x0
R/W
0000
Chip Slot 1 Used.
0001
Chip Slot 2 Used.
0010
Chip Slot 3 Used.
0011
Chip Slot 4 Used.
0100
Chip Slot 5 Used.
0101
Chip Slot 6 Used.
0110
Chip Slot 7 Used.
0111
Chip Slot 8 Used.
1000
Chip Slot 9 Used.
1001
Chip Slot 10 Used.
1010
Chip Slot 11 Used.
1011
Chip Slot 12 Used.
1100
Chip Slot 13 Used.
1101
Chip Slot 14 Used.
1110
Chip Slot 15 Used.
1111
Chip Slot 16 Used.
7
0
6
0
5
0
4
0
3
0
2
0
1
0
0
0
[7] DATA_W IDTH (R/W)
Audio Data W idth
0: Audio input on SDATA is 24 bits.
1: Audio input on SDATA is 16 bits.
[3:0] TDM_SLOT (R/W)
TDM Slot Selection
0000: Chip Slot 1 Used.
0001: Chip Slot 2 Used.
0010: Chip Slot 3 Used.
...
1101: Chip Slot 14 Used.
1110: Chip Slot 15 Used.
1111: Chip Slot 16 Used.
[6:5] RESERVED
[4] AUTO_SLOT (R/W)
Automatic TDM Slot Selection
0: TDM Slot determined byTDM_SLOT register.
1: TDM Slot determined byADDR pin.
