background image
Data Sheet
SSM3515
Rev. A| Page 41 of 41
OUTLINE DIMENSIONS
A
B
C
D
E
2.240
2.200
2.160
1.840
1.800
1.760
1
2
3
4
BOTTOM VIEW
(BALL SIDE UP)
TOP VIEW
(BALL SIDE DOWN)
BALL A1
IDENTIFIER
0.40
BSC
0.560
0.500
0.440
SIDE VIEW
0.230
0.200
0.170
0.300
0.260
0.220
1.60 REF
1.20 REF
COPLANARITY
0.05
SEATING
PLANE
Figure 76. 20-Ball Wafer Level Chip Scale Package [WLCSP]
(CB-20-10)
Dimensions shown in millimeters
ORDERING GUIDE
Model1
Temperature Range
Package Description
Package Option
SSM3515CCBZ-RL
−40°C to +85°C
20-Ball Wafer Level Chip Scale Package [WLCSP]
CB-20-10
SSM3515CCBZ-R7
−40°C to +85°C
20-Ball Wafer Level Chip Scale Package [WLCSP]
CB-20-10
EVAL-SSM3515Z
Evaluation Board
1 Z = RoHS Compliant Part.
I2C refers to a communications protocol originally developed by Philips Semiconductors (now NXP Semiconductors).
©2015–2017 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
D13327-0-1/17(A)
