6

Digital Controller

E5AK/E5EK

■ Output Unit Ratings and Characteristics

Note: An output relay (1 A at 250 VAC) is mounted on the position-proportional model. (When replacing, use the E53-R.)

■ Option Unit Ratings and Characteristics

■ Current Transformer Ratings

■ Heater Burnout Alarm

Note: 1. Use the K2CU-F

@@A-@GS (with gate input terminals) for the detection of three-phase heater burnout.

2. The heater burnout alarm is always OFF if the alarm is set to 0.0 A and always ON if the alarm is set to 50.0 A.

3. No heater burnout detection or heater current value measurement is possible if the control output (heat) is ON for less than 190 ms.

Relay output

5 A at 250 VAC (resistive load)

SSR output

1 A at 75 to 250 VAC (resistive load)

Voltage output

NPN: 40 mA at 12 VDC (with short-circuit protection)

NPN: 20 mA at 24 VDC (with short-circuit protection)

PNP: 20 mA at 24 VDC (with short-circuit protection)

Linear current output

4 to 20 mA, permissible load impedance: 600

Ω max., resolution: approx. 2,600

0 to 20 mA, permissible load impedance: 600

Ω max., resolution: approx. 2,600

Linear voltage output

0 to 10 VDC, permissible load impedance: 1 k

Ω max., resolution: approx. 2,600

0 to 5 VDC, permissible load impedance: 1 k

Ω max., resolution: approx. 2,600

Event inputs

Contact input:

ON: 1 k

Ω max., OFF: 100 kΩ min.

No-contact input:

ON: residual voltage 1.5 V max., OFF: leakage current 0.1 mA max.

Communications

Interface:

RS-232C, RS-422 or RS-485

Transmission method:

Half-duplex

Synchronization method: Start-stop synchronization (asynchronous method)

Baud rate:

1.2/2.4/4.8/9.6/19.2 kbps

Transmission code:

ASCII

Transfer output

4 to 20 mA:

Permissible load impedance: 600

Ω max.

Resolution: approx. 2,600

Dielectric strength

1,000 VAC (for 1 min)

Vibration resistance

Weight

E54-CT1: approx. 11.5 g; E54-CT3: approx. 50 g

Accessories (E54-CT3 only)

Armature: 2; Plug: 2

Max. heater current

Single-phase 50 A VAC (see note 1)

Heater current value display accuracy

±5% FS±1 digit max.

Heater burnout alarm setting range

0.1 to 49.9 A (in units of 0.1 A) (see note 2)

Min. detection ON time

190 ms (see note 3)
