13 / 205 page  Data Sheet AD9546 Rev. 0 | Page 13 of 205 Parameter Min Typ Max Unit REFAA 1.8 V CMOS Aggressor Reference and Input Mode REFB Differential AC-Coupled −76 dBc REFB Differential LVDS −76 dBc REFBB 1.2 V CMOS −76 dBc REFBB 1.8 V CMOS −76 dBc REFBB Single-Ended AC-Coupled −76 dBc REFAA Single-Ended AC-Coupled Aggressor Reference and Input Mode REFB Differential AC-Coupled −75 dBc REFB Differential LVDS −75 dBc REFBB 1.2 V CMOS −76 dBc REFBB 1.8 V CMOS −76 dBc REFBB Single-Ended AC-Coupled −76 dBc REFB or REFBB Using Any Single-Ended Input Mode Aggressor Reference (Not REFA or REFAA) M0, M1, M2, or M3 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −66 dBc REFBB Using Any Single-Ended Input Mode Aggressor Reference (Not REFA or REFAA) M0, M1, or M2 (Not M3) with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −74 dBc REFB and REFBB Using Any Differential Input Mode Aggressor Reference (Not REFA or REFAA) M0, M1, M2, or M3 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −70 dBc M0 with VDDIOx = 1.8 V or 3.3 V Aggressor Reference (Not REFA or REFAA) REFB or REFBB Using Any Input Mode; or M1, M2, or M3 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −65 dBc M0 with VDDIOx = 1.8 V or 3.3 V Aggressor Reference (Not REFA or REFAA) REFB or REFBB Using Any Input Mode; or M2 or M3 (Not M1) with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −70 dBc M1 with VDDIOx = 1.8 V or 3.3 V Aggressor Reference (Not REFA or REFAA) REFB or REFBB Using Any Input Mode; or M0, M2, or M3 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −68 dBc M2 with VDDIOx = 1.8 V or 3.3 V Aggressor Reference (Not REFA or REFAA) REFB or REFBB Using Any Input Mode; or M1, M3, or M4 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −67 dBc M3 with VDDIOx = 1.8 V or 3.3 V Aggressor Reference (Not REFA or REFAA) REFB or REFBB Using Any Input Mode; or M0, M1, or M2 with VDDIOx = 1.8 V or 3.3 V; and Connected to Any Auxiliary Reference −69 dBc M3 with VDDI0x = 3.3 V (Not 1.8 V) Aggressor Reference (Not REFA, REFAA, REFB, or REFBB) M0, M1, or M2 with VDDIOx = 3.3 V (Not 1.8 V); and Connected to Any Auxiliary Reference −80 dBc |
|
