background image
Page 13 of 40
Multi Spider - ORG4572 Datasheet
Revision 3.0
November 23, 2014
13. ELECTRICAL SPECIFICATIONS
13.1. ABSOLUTE MAXIMUM RATINGS
Stresses exceeding Absolute Maximum Ratings may damage the device.
PARAMETER
SYMBOL
MIN
MAX
UNIT
Power Supply Voltage
VCC
-0.30
+2.20
V
Power Supply Current
1
ICC
150
mA
RF Input Voltage
VRF
-25
+25
V
I/O Voltage
VIO
-0.30
+3.65
V
I/O Source/Sink Current
IIO
-4
+4
mA
ESD Rating
I/O pads
HBM
2 method
VIO(ESD)
-2000
+2000
V
CDM
3 method
-400
+400
V
RF input pad
HBM
2 method
VRF(ESD)
-2000
+2000
V
RF Input Power
fIN = 1560MHz÷1630MHz‎
PRF
0
dBm
fIN <1560MHz, >1630MHz‎
0
dBm
Power Dissipation
PD
350
mW
Operating Temperature
TAMB
-45
+90
°C
Storage Temperature
TST
-55
+150
°C
Lead Temperature
4
TLEAD
+260
°C
TABLE 3 – ABSOLUTE MAXIMUM RATINGS
Notes:
1. Inrush current of up to 150mA for about 20µs duration.
2. Human Body Model (HBM) contact discharge per EIA/JEDEC JESD22-A114D.
3. Charged Device Model (CDM) contact discharge per JEDEC EIA/JESD22-C101.
4. Lead temperature at 1mm from case for 10s duration.
