Cable Entry System Frames for Terminated Cables - Round

• Requires the use of CEG grommets to achieve sealing properties (see page 4)

— Small Grommets accommodate 0.08" – 0.47" cable diameters

— Medium Grommets accommodate 0.47" – 0.87" cable diameters

— Large Grommets accommodate 0.87" – 1.18" cable diameters

• Split locknut included

• Cable grommets available for ASI cables

• IP65 (NEMA Type 1 and 12)

• Manufactured from polyamide 6 materials

• Flammability: UL94V-0

• Temperature rating: -22 °F – 212 °F (-30 °C – 100 °C)

• Installs into a 2" (50.5mm) round hole

• Requires the use of CEG grommets to achieve sealing properties (see page 4)

— Small Grommets accommodate 0.08" – 0.47" cable diameters

• Incorporates integrated strain relief

• Requires four (4) user supplied 10-32 screws and nuts for mounting

• IP65 (NEMA Type 1, 12, and 4X indoor use only)

• Manufactured from polypropylene and TPE materials

• Flammability: UL94V-0

• Temperature rating: -22 °F – 212 °F (-30 °C – 100 °C)

Part Number

Total

Number of

Openings

Number of Grommets

and Size Required

Overall Dimensions

Std. Pkg.

Qty.

Std. Ctn.

Qty.

Small

Medium

Large

Diameter

Installed Height

in

mm

in

mm

CEST2-RL251

1

1

0

0

1.57

39.9

0.73

18.5

5

50

CEST2-RL321

0

1

1.97

50.0

0.71

18.0

CEST2-RL401

2.44

62.0

CEST2-RL501

0

1

62.0

0.87

22.1

Part Number

Total

Number of

Openings

Number of Grommets

and Size Required

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Small

Medium

Large

Length

Width

Installed Height

in

mm

in

mm

in

mm

CEST2-R504

4

4

0

0

2.44

62.0

2.44

62.0

0.71

18.0

1

50

For cutout dimensions, scan the QR code

or visit www.panduit.com/cable-entry-system-drawings

Cable Entry Systems
