Part Number

Total

Number of

Openings

Number of

Openings

Size of Openings

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Diameter

Installed Height

In

mm

In

mm

In

mm

CESU2-RL504

4

3

0.24 - 0.39

6.1 - 9.9

2.28

58.0

0.35

8.9

1

50

1

0.38 - 0.63

9.7 - 16.0

CESU2-RL506

6

1

0.12 - 0.22

3.0 - 5.6

5

0.20 - 0.36

5.1 - 9.1

CESU2-RL508

8

7

0.14 - 0.26

3.6 - 6.6

1

0.24 - 0.39

6.1 - 9.9

CESU2-RL5031

31

31

0.06 - 0.12

1.5 - 3.0

CESU2-RL638

8

2

0.12 - 0.26

3.0 - 6.6

2.80

71.0

4

0.20 - 0.36

5.1 - 9.1

2

0.38 - 0.63

9.7 - 16.0

CESU2-RL6313

13

6

0.12 - 0.22

3.0 - 5.6

0.14 - 0.26

3.6 - 6.6

1

0.24 - 0.39

6.1 - 9.9

CESU2-RL6319

19

19

0.12 - 0.20

3.0 - 5.1

CESU2-RL6346

46

46

0.06 - 0.12

1.5 - 3.0

Part Number

Total

Number of

Openings

Number of

Openings

Size of Openings

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Diameter

Installed Height

In

mm

In

mm

In

mm

CESUM3-R406

6

1

0.08 - 0.16

2.0 - 4.0

1.9

48.5

0.33

8.5

5

50

2

0.12 - 0.24

3.0 - 6.0

2

0.20 - 0.35

5.0 - 9.0

1

0.30 - 0.47

7.5 - 12.0

CESUM3-R407

7

4

0.12 - 0.24

3.0 - 6.0

3

0.20 - 0.35

5.0 - 9.0

Cable Entry System for Un-Terminated Cables - Round

• Engineered cable entry system offering a high degree of strain relief

• For snap-in fastening or securing in place with a locknut

• Snaps into panel thickness of 0.06" to 0.08"

• Locknut included is used for securement but is not UL approved

• IP65 (NEMA 1)

• Manufactured from polyamide 6.6 and NBR/EPDM materials

• Temperature rating: -22 °F – 194 °F (-30 °C – 90 °C)

• Membrane plate cable entry system offering good strain relief

• For snap-in fastening or screwing in place with a locknut (not included)

• Snaps into panel thickness of 0.06" to 0.08"

• IP65 (NEMA 12 and 4X - indoor/horizontal mount only)

• Manufactured from polyamide 6.6 and NBR/EPDM materials

• Temperature Rating: -22 °F – 194 °F (-30 °C – 90 °C)

For cutout dimensions, scan the QR code

or visit www.panduit.com/cable-entry-system-drawings

Cable Entry Systems
