Cable Entry System for Un-Terminated Cables - Rectangular

• Engineered cable entry system offering a high degree of strain relief

• For snap-in fastening and/or screwing in place with four (4) user supplied

10-32 screws and nuts

• Snap-in at plate thickness of 0.06" to 0.08" thick

• Identification area suitable for label part number T024X000FJM-BK

printed with the Panduit MP75, MP100, MP200, or MP300 printer.

• Ports feature an innovative polymer membrane that gives a high

quality fit around cables and a high degree of strain relief.

• IP65 (NEMA Type 1 and 12)

• Manufactured from polyamide 6.6 and TPU/EPDM materials

• Flammability: UL94V-0

• Temperature rating: -22 °F – 212 °F (-30 °C – 100 °C)

Part

Number

Total

Number of

Openings

Number of

Openings

Size of Openings

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Length

Width

Installed Height

In

mm

In

mm

In

mm

In

mm

CESU2-E10

10

2

0.12 - 0.26

3.0 - 6.6

5.79

147.1

2.32

58.9

0.59

15.0

1

50

1

0.20 - 0.36

5.1 - 9.1

5

0.35 - 0.55

8.9 - 14.0

2

0.55 - 0.79

14.0 - 20.1

CESU2-E11

11

4

0.12 - 0.26

3.0 - 6.6

0.20 - 0.36

5.1 - 9.1

3

0.55 - 0.79

14.0 - 20.1

CESU2-E12

12

12

0.31 - 0.47

7.9 - 11.9

CESU2-E13

13

2

0.12 - 0.22

3.0 - 5.6

6

0.16 - 0.32

4.1 - 8.1

4

0.35 - 0.55

8.9 - 14.0

1

0.55 - 0.79

14.0 - 20.1

CESU2-E14

14

6

0.12 - 0.26

3.0 - 6.6

4

0.20 - 0.36

5.1 - 9.1

4

0.38 - 0.63

9.7 - 16.0

CESU2-E17

17

17

0.20 - 0.36

5.1 - 9.1

CESU2-E17A

17

11

0.12 - 0.26

3.0 - 6.6

1

0.16 - 0.32

4.1 - 8.1

5

0.31 - 0.49

7.9 - 12.4

CESU2-E22

22

16

0.12 - 0.26

3.0 - 6.6

4

0.20 - 0.36

5.1 - 9.1

2

0.31 - 0.49

7.9 - 12.4

CESU2-E23

23

23

0.16 - 0.32

4.1 - 8.1

CESU2-E29

29

29

0.12 - 0.26

3.0 - 6.6

For cutout dimensions, scan the QR code

or visit www.panduit.com/cable-entry-system-drawings

Cable Entry Systems
