Cable Entry Membrane Plate for Un-Terminated Cables - Rectangular

• Membrane plate cable entry system offering good strain relief

• Requires four (4) user supplied 10-32 screws and nuts for mounting

• IP66 (NEMA Type 12 and 4X indoor use only)

• Manufactured from polypropylene (frame) and TPE (seal)

• Flammability: UL94V-0 Frame and UL94-HB Seal

• Temperature rating: -22 °F – 158 °F (-30 °C – 70 °C)

*Reference Greenlee website for appropriate punch tools to accommodate cutouts above

Part

Number

Total

Number of

Openings

Number of

Openings

Size of Openings

Overall Dimensions

Std.

Pkg.

Qty.

Std.

Ctn.

Qty.

Length

Width

Installed Height

In

mm

In

mm

In

mm

In

mm

CESUM3-C14

14

14

0.20 - 0.35

5.00 - 9.00

4.1

103.0

2.4

61.0

0.59

15.0

5

50

CESUM3-C15

15

8

0.12 - 0.31

3.00 - 8.00

3

0.20 - 0.35

5.00 - 9.00

4

0.30 - 0.47

7.50 - 12.00

CESUM3-D10

10

10

0.30 - 0.47

7.50 - 12.00

4.8

123.0

CESUM3-D12

12

2

0.12 - 0.20

3.00 - 5.00

4

0.20 - 0.35

5.00 - 9.00

2

0.30 - 0.47

7.50 - 12.00

2

0.39 - 0.63

10.00 - 16.00

2

0.55 - 0.79

14.00 - 20.00

CESUM3-D17

17

17

0.20 - 0.35

5.00 - 9.00

CESUM3-D24

24

16

0.12 - 0.24

3.00 - 6.00

6

0.20 - 0.35

5.00 - 9.00

2

0.30 - 0.47

7.50 - 12.00

CESUM3-E14

14

14

0.30 - 0.47

7.50 - 12.00

5.87

149.1

CESUM3-E23

23

23

0.20 - 0.35

5.00 - 9.00

For cutout dimensions, scan the QR code

or visit www.panduit.com/cable-entry-system-drawings
