FT800 Embedded Video Engine Datasheet

Version 1.4

Document No.: BRT_000039 Clearance No.: BRT#001

Pin No.

Name

Type

Description

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 3 of Green RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 2 of Green RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 7 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 6 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 5 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 4 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 3 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

Bit 2 of Red RGB signals, push-pull output,

4/8mA sink/source current.

Pad powered from pin VCC.

GND

Ground. Exposed thermal pad.

Table 3-1 FT800Q pin description

Note:

: Power or ground

: Input

: Output

: Open drain output

I/O

: Bi-direction Input and Output

AI/O

: Analog Input and Output
