Features

•

Compatible with following I2C bus modes:

–

1 MHz

–

400 kHz

–

100 kHz

•

Memory array:

–

2 Mbit (256 Kbyte) of EEPROM

–

Page size: 256 byte

–

Additional write lockable page (M24M02-DR order codes)

•

Single supply voltage:

–

1.8 V to 5.5 V over –40 °C / +85 °C

•

Write time:

–

Byte write within 10 ms

–

Page write within 10 ms

•

Random and sequential read modes

•

Write protect of the whole memory array

•

Enhanced ESD/latch-Up protection

•

More than 4 million write cycles

•

More than 200-years data retention

•

Packages:

–

SO8N ECOPACK2

–

WLCSP ECOPACK2

–

Unsawn wafer (each die is tested)

–

RoHS compliant and halogen-free (ECOPACK2)

SO8N (MN)

150 mil width

WLSCP

Unsawn wafer

Product status link

M24M02-DR

M24M02-R

2-Mbit serial I²C bus EEPROM

M24M02-DR M24M02-R

Datasheet

DS7025 - Rev 11 - October 2022

For further information contact your local STMicroelectronics sales office.

www.st.com
