STM32U545xx

Electrical characteristics

258

5.3.30

PSSI characteristics

Unless otherwise specified, the parameters given in the table below are derived from tests

performed under the ambient temperature, fHCLK frequency and VDD supply voltage

summarized in Table 33, with the following configuration:

•

Output speed set to OSPEEDRy[1:0] = 10

•

PSSI_PDCK polarity: falling

•

PSSI_RDY and PSSI_DE polarity: low

•

Bus width: 16 lines

•

Data width: 32 bits

•

Capacitive load CL = 30 pF

•

Measurement points done at 0.5 × VDD level

•

I/O compensation cell activated

•

HSLV activated when VDD ≤ 2.7 V

•

Voltage scaling range 1

Table 121. PSSI transmit characteristics(1)

Symbol

Parameter

Conditions

Min

Max

Unit

Frequency ratio DCMI_PDCK/fHCLK

0.4

PSSI_PDCK PSSI clock input

2.7 V ≤ VDD ≤ 3.6 V

64(2)

MHz

1.71 V ≤ VDD ≤ 3.6 V

47(2)

DPIXEL

PSSI clock input duty cycle

tOV(DATA)

Data output valid time

2.7 V ≤ VDD ≤ 3.6 V

1.71 V ≤ VDD ≤ 3.6 V

tOH(DATA)

Data output hold time

1.71 V ≤ VDD ≤ 3.6 V

tOV(DE)

DE output valid time

12.5

tOH(DE)

DE output hold time

tSU(RDY)

RDY input setup time

1.71 V ≤ VDD ≤ 3.6 V

tH(RDY)

RDY input hold time

1. Evaluated by characterization. Not tested in production.

2. This maximal frequency does not consider receiver setup and hold timings.
