Type/Order Text

Ref.-No.

Patch Cable, Multimode 50/125/250µm

Factory made VF-45 Duplex patch cables in various lengths are

used for patching between sockets or for making the connection to

transceivers on the workstation, hub or switch. Hybrid cables to

connect ST, SC, LC and MTRJ interfaces are also available.

Other Hybrids available upon request.

Note: During 2005, the patch cables will be changed to a universal

type, which is both riser and LSZH rated. Reference numbers will

change. For example: from VOL-V5L1 to VOL-V5L/R1

Highlights:

• Duplex connection

• Factory made VF-45 duplex patch cables in various lengths

• Automatic dust protection protects fibres in unmated

condition

• Tested to TIA/EIA and IEC performance requirements

• Patchcords made with 3M’s innovative coated fibre, GGP,

minimum bend radius 25mm

1.2

Fibre Cabling

1.2.5

Volition™ Patch Cable

Multimode 50/125/250µm

Description

VF-45-Connector to VF-45-Connector, 50/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-V5L1

1,5 m

VOL-V5L1,5

VOL-V5L2

VOL-V5L3

VOL-V5L5

VOL-V5L8

15 m

VOL-V5L15

30 m

VOL-V5L30

VF-45-Connector to ST-Connector, 50/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-T5L1

VOL-T5L2

VOL-T5L3

VOL-T5L5

VOL-T5L8

15 m

VOL-T5L15

30 m

VOL-T5L30

VF-45-Connector to SC-Connector, 50/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-C5L1

1,5 m

VOL-C5L1,5

VOL-C5L2

VOL-C5L3

VOL-C5L5

VOL-C5L8

15 m

VOL-C5L15

30 m

VOL-C5L30

VF-45™-Connector to MTRJ-Connector, 50/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-M5L1

VOL-M5L2

VOL-M5L3

VOL-M5L5

VOL-M5L8

10 m

VOL-M5L10

35 m

VOL-M5L35

VF-45™-Connector to LC-Connector, 50/125µm, LSZH

PU: 12

MOQ: 1

Length:

1 m

VOL-L5L1

1,5 m

VOL-L5L1,5

VOL-L5L2

VOL-L5L3

VOL-L5L5

VOL-L5L8
