7. ORDERING INFORMATION

8. REVISION HISTORY

Product

Description

Package

Pb-Free

Grade

Temp Range

Container

Order #

CS5341

105 dB, 192 kHz, Multi-Bit

Audio A/D Converter

16-TSSOP

YES

Commercial

-10° to +70° C

Bulk

CS5341-CZZ

Tape & Reel

CS5341-CZZR

CS5341

105 dB, 192 kHz, Multi-Bit

Audio A/D Converter

16-TSSOP

YES

Automotive

-40° to +85° C

Bulk

CS5341-DZZ

Tape & Reel

CS5341-DZZR

CDB5341

CS5341 Evaluation Board

-

-

-

-

-

CDB5341

Release

Changes

A1

Initial Advance release

A2

Updated serial port timing specifications

PP1

Change value of capacitors in analog input buffer diagram

Update Sample Rate range

Added Applications section on FILT+ filter capacitor

Add CS5341-CZZ as part number

Replace available part number CS5341-DZ with CS5341-DZZ

Initial Preliminary product release

PP2

Add lead-free option to ordering information

F1

Remove CS5341-CZ from Ordering Information

Redefine Serial Audio Port Switching Characteristics

Correct dimension “e” under Package Dimensions

Update maximum current and power specifications

Update Filt+ output impedance specification
