DS564F1

CS5341

1. CHARACTERISTICS AND SPECIFICATIONS

(All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical

performance characteristics and specifications are derived from measurements taken at typical supply voltages

SPECIFIED OPERATING CONDITIONS

(GND = 0 V, all voltages with respect to 0 V.)

Notes:

1.

This part is specified at typical analog voltages of 3.3 V and 5.0 V. See Analog Characteristics - Com-

mercial Grade and Analog Characteristics - Automotive Grade, below, for details.

ABSOLUTE MAXIMUM RATINGS

(GND = 0 V, All voltages with respect to ground.) (Note 2)

2.

Operation beyond these limits may result in permanent damage to the device.

Normal operation is not guaranteed at these extremes.

3.

Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause

SRC latch-up.

4.

The maximum over/under voltage is limited by the input current.

Parameter

Symbol

Min

Typ

Max

Unit

Power Supplies

Analog

Digital

Logic

VA

VD

VL

3.1

3.1

1.7

(Note 1)

3.3

3.3

5.25

5.25

5.25

V

V

V

Ambient Operating Temperature

Commercial

Automotive

-10

-40

-

-

70

85

°C

°C

Parameter

Symbol

Min

Max

Units

DC Power Supplies:

Analog

Logic

Digital

VA

VL

VD

-0.3

-0.3

-0.3

+6.0

+6.0

+6.0

V

V

V

Input Current

(Note 3)

-10

+10

mA

Analog Input Voltage

(Note 4)

GND-0.7

VA+0.7

V

Digital Input Voltage

(Note 4)

-0.7

VL+0.7

V

Ambient Operating Temperature (Power Applied)

-50

+95

°C

Storage Temperature

-65

+150

°C
