6.9 Timing and Switching Characteristics
Note
The Timing Requirements and Switching Characteristics values may change following the silicon
characterization result.
Note
The default SLEWRATE settings in each pad configuration register must be used to ensure timings,
unless specific instructions are given otherwise.
6.9.1 Timing Parameters and Information
The timing parameter symbols used in Section 6.9, Timing and Switching Characteristics are created in
accordance with JEDEC Standard 100. To shorten the symbols, some pin names and other related terminologies
have been abbreviated in Table 6-3:
Table 6-3. Timing Parameters Subscripts
SYMBOL
PARAMETER
c
Cycle time (period)
d
Delay time
dis
Disable time
en
Enable time
h
Hold time
su
Setup time
START
Start bit
t
Transition time
v
Valid time
w
Pulse duration (width)
X
Unknown, changing, or don't care level
F
Fall time
H
High
L
Low
R
Rise time
V
Valid
IV
Invalid
AE
Active Edge
FE
First Edge
LE
Last Edge
Z
High impedance
TDA4VEN-Q1, TDA4AEN-Q1
SPRSP96A – MARCH 2024 – REVISED SEPTEMBER 2024
www.ti.com
94
Submit Document Feedback
Copyright © 2024 Texas Instruments Incorporated
Product Folder Links: TDA4VEN-Q1 TDA4AEN-Q1
