MIC24054
FIGURE 2-42:
Power-Up into Short Circuit.
FIGURE 2-43:
Enabled into Short.
FIGURE 2-44:
Short Circuit.
FIGURE 2-45:
Output Recovery from Short
Circuit.
FIGURE 2-46:
Output Current-Limit
Threshold.
FIGURE 2-47:
Output Recovery Time from
Thermal Shutdown.
V
IN = 12V
V
OUT = 1.8V
I
OUT = 5A
Time (5ms/div)
V
OUT
(1V/div)
I
L
(5A/div)
V
IN = 12V
V
OUT = 1.8V
Time (1ms/div)
V
OUT
(1V/div)
I
OUT
(5A/div)
