652 / 1504 page ![]() Section 13 I/O Ports Rev. 2.00 Sep. 24, 2008 Page 620 of 1468 REJ09B0412-0200 (5) P33/PO11/TIOCC0/TIOCD0/TCLKB-A/ DREQ1-B/EDREQ3 The pin function is switched as shown below according to the combination of the TPU and PPG register settings and P33DDR bit setting. Setting TPU PPG I/O Port Module Name Pin Function TIOCD0_OE PO11_OE P33DDR TPU TIOCD0 output 1 — — PPG PO11 output 0 1 — P33 output 0 0 1 I/O port P33 input (initial value) 0 0 0 (6) P32/PO10/TIOCC0/TCLKA-A/ DACK0-B/EDACK2 The pin function is switched as shown below according to the combination of the EXDMAC, DMAC, TPU, and PPG register settings and P32DDR bit setting. Setting EXDMAC DMAC TPU PPG I/O Port Module Name Pin Function EDACK2_OE DACK0B_OE TIOCC0_OE PO10_OE P32DDR EXDMAC EDACK2 output 1 DMAC DACK0-B output 0 1 TPU TIOCC0 output 0 0 1 PPG PO10 output 0 0 0 1 P32 output 0 0 0 0 1 I/O port P32 input (initial value) 0 0 0 0 0 |
|
