H8SX/1663M 데이터시트(PDF) 656 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663M 데이터시트(HTML) 656 Page - Renesas Technology Corp |
|
|
656 / 1504 page  Section 13 I/O Ports Rev. 2.00 Sep. 24, 2008 Page 624 of 1468 REJ09B0412-0200 (4) P62/TMO2/SCK4/ DACK2/EDACK0-B/IRQ10-B/TRST The pin function is switched as shown below according to the combination of the EXDMAC, DMAC, TMR, and SCI register settings and P62DDR bit setting. Setting EXDMAC DMAC TMR SCI I/O Port Module Name Pin Function MCU Operation Mode EDACK0B_OE DACK2_OE TMO2_OE SCK4_OE P62DDR EXDMAC EDACK0-B output 1 DMAC DACK2 output 0 1 TMR TMO2 output 0 0 1 SCI SCK4 output 0 0 0 1 P62 output 0 0 0 0 1 I/O port P62 input (initial value) Except for boundary scan enabled mode* 0 0 0 0 0 Note: * These pins are boundary scan dedicated input pins during boundary scan enabled mode. (5) P61/TMCI2/RxD4/ TEND2/ETEND0-B/IRQ9-B The pin function is switched as shown below according to the combination of the EXDMAC and DMAC register settings and P61DDR bit setting. Setting EXDMAC DMAC I/O Port Module Name Pin Function ETEND0B_OE TEND2_OE P61DDR EXDMAC ETEND0-B output 1 DMAC TEND2 output 0 1 P61 output 0 0 1 I/O port P61 input (initial value) 0 0 0 |
|
