H8SX/1663M 데이터시트(PDF) 653 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663M 데이터시트(HTML) 653 Page - Renesas Technology Corp |
|
|
653 / 1504 page  Section 13 I/O Ports Rev. 2.00 Sep. 24, 2008 Page 621 of 1468 REJ09B0412-0200 (7) P31/PO9/TIOCA0/TIOCB0/ TEND0-B/ETEND2 The pin function is switched as shown below according to the combination of the EXDMAC, DMAC, TPU, and PPG register settings and P31DDR bit setting. Setting EXDMAC DMAC TPU PPG I/O Port Module Name Pin Function ETEND2_OE TEND0B_OE TIOCB0_OE PO9_OE P31DDR EXDMAC ETEND2 output 1 DMAC TEND0-B output 0 1 TPU TIOCB0 output 0 0 1 PPG PO9 output 0 0 0 1 P31 output 0 0 0 0 1 I/O port P31 input (initial value) 0 0 0 0 0 (8) P30/PO8/TIOCA0/ DREQ0-B/EDREQ2 The pin function is switched as shown below according to the combination of the TPU and PPG register settings and P33DDR bit setting. Setting TPU PPG I/O Port Module Name Pin Function TIOCA0_OE PO8_OE P30DDR TPU TIOCA0 output 1 PPG PO8 output 0 1 P30 output 0 0 1 I/O port P30 input (initial value) 0 0 0 |
|
