MSC8152 Dual-Core Digital Signal Processor Data Sheet, Rev. 1

Electrical Characteristics

Freescale Semiconductor

2.2

Recommended Operating Conditions

Table 3 lists recommended operating conditions. Proper device operation outside of these conditions is not guaranteed.

Table 3. Recommended Operating Conditions

Rating

Symbol

Min

Nominal

Max

Unit

Core supply voltage

VDD

0.97

1.0

1.05

M3 memory supply voltage

VDDM3

0.97

1.0

1.05

MAPLE-B supply voltage

VDDM

0.97

1.0

1.05

DDR memory supply voltage

• DDR2 mode

• DDR3 mode

DDR reference voltage

VDDDDR

MVREF

1.7

1.425

0.49

× VDDDDR

1.8

1.5

0.5

× VDDDDR

1.9

1.575

0.51

× VDDDDR

I/O voltage excluding DDR and

RapidIO lines

VDDIO

2.375

2.5

2.625

Rapid I/O pad voltage

VDDSXP

0.97

1.0

1.05

Rapid I/O core voltage

VDDSXC

0.97

1.0

1.05

Operating temperature range:

• Standard

• Higher

• Extended

–40

—

105

—

105

°C
