MSC8152 Dual-Core Digital Signal Processor Data Sheet, Rev. 1
Pin Assignment
Freescale Semiconductor
4
1
Pin Assignment
This section includes diagrams of the MSC8152 package ball grid array layouts and tables showing how the pinouts are
allocated for the package.
1.1
FC-PBGA Ball Layout Diagram
The top view of the FC-PBGA package is shown in Figure 3 with the ball location index numbers.
Figure 3. MSC8152 FC-PBGA Package, Top View
MSC8154
Top View
