 98 / 143 page
background image
Command codes
M24LR16E-R
98/143
Doc ID 018932 Rev 8
Response parameter:
●
No parameter.
Response parameter:
●
Error code as Error_flag is set:
–
11h: the specified block is already locked and thus cannot be locked again
–
14h: the specified block was not successfully locked
.
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Lock DSFID command to the end of the M24LR16E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin is tied to 0 for the
duration of the internal write cycle (from the end of a valid Lock DSFID command to the
beginning of the M24LR16E-R response).
Table 68.
Lock DSFID response format when Error_flag is set
Response
SOF
Response_flags
Error code
CRC16
Response
EOF
8 bits
8 bits
16 bits
Figure 64.
Lock DSFID frame exchange between VCD and M24LR16E-R
VCD
SOF
Lock
DSFID
request
EOF
M24LR16E-R
<-t1-> SOF
Lock DSFID
response
EOF
Lock sequence
when error
M24LR16E-R
<---------------- Wt -------------> SOF
Lock
DSFID
response
EOF
