Command codes
M24LR16E-R
100/143
Doc ID 018932 Rev 8
Response parameters:
●
Information flags set to 0Fh. DSFID, AFI, Memory Size and IC reference fields are
present.
●
UID code on 64 bits
●
DSFID value
●
AFI value
●
Memory size. The M24LR16E-R provides 512 blocks (01FFh) of 4 byte (03h)
●
IC reference: the 8 bits are significant.
Response parameter:
●
Error code as Error_flag is set:
–
03h: Option not supported
.
When configured in the RF busy mode, the RF WIP/BUSY pin is tied to 0 from the SOF that
starts the Get System Info command to the end of the M24LR16E-R response.
When configured in the RF write in progress mode, the RF WIP/BUSY pin remains in high-Z
state.
Table 72.
Get System Info response format when Error_flag is set
Response
SOF
Response_flags
Error code
CRC16
Response
EOF
01h
8 bits
16 bits
Figure 65.
Get System Info frame exchange between VCD and M24LR16E-R
VCD
SOF
Get System Info
request
EOF
M24LR16E-R
<-t1-> SOF
Get System Info
response
EOF
