background image
M24LR16E-R
Command codes
Doc ID 018932 Rev 8
99/143
26.12
Get System Info
When receiving the Get System Info command, the M24LR16E-R sends back its information
data in the response.The Option_flag is not supported. The Get System Info can be issued
in both Addressed and Non Addressed modes.
The Protocol_extension_flag can be set to 0 or 1. Table 70 and Table 72 show M24LR16E-R
response to the Get System Info command depending on the value of the
Protocol_extension_flag.
Request parameter:
●
Request flags
●
UID (optional)
Response parameters:
●
Information flags set to 0Ch. DSFID, AFI and IC reference fields are present.
●
UID code on 64 bits
●
DSFID value
●
AFI value
●
M24LR16E-R IC reference: the 8 bits are significant.
Table 69.
Get System Info request format
Request
SOF
Request
_flags
Get System
Info
UID(1)
1.
Gray means that the field is optional.
CRC16
Request
EOF
8 bits
2Bh
64 bits
16 bits
Table 70.
Get System Info response format when Protocol_extension_flag = 0 and
Error_flag is NOT set
Response
SOF
Response
_flags
Information
flags
UID
DSFID
AFI
IC ref.
CRC16
Response
EOF
00h
0Bh
64 bits
8 bits
8 bits
4Eh
16 bits
Table 71.
Get System Info response format when Protocol_extension_flag = 1 and
Error_flag is NOT set
Response
SOF
Response
_flags
Information
flags
UID
DSFID
AFI
Memory
size
IC
ref.
CRC
16
Response
EOF
00h
0Fh
64
bits
8 bits
8 bits
0301FF
4Eh
16
bits
