background image
ADP5050
Data Sheet
Rev. 0 | Page 46 of 60
REGISTER 7: LCH_CFG (SHORT-CIRCUIT LATCH-OFF
AND OVERVOLTAGE LATCH-OFF CONFIGURATION),
ADDRESS 0x07
Register 7 is used to enable and disable the latch-off function for
short-circuit protection (SCP) and overvoltage protection (OVP).
When the SCP or OVP latch-off function is enabled, the
CHx_LCH bit in Register 12 is set after an error condition
occurs (see the Latch-Off Protection section). The default value
for the SCP latch-off and OVP latch-off functions can be
programmed by factory fuse (SCP or OVP latch-off function
enabled or disabled for all four buck regulators).
Table 31. Register 7 Bit Assignments
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
OVP4_ON
OVP3_ON
OVP2_ON
OVP1_ON
SCP4_ON
SCP3_ON
SCP2_ON
SCP1_ON
Table 32. LCH_CFG Register, Bit Function Descriptions
Bits
Bit Name
Access
Description
7
OVP4_ON
R/W
The default value is programmed by factory fuse.
0 = disable the OVP latch-off function for Channel 4.
1 = enable the OVP latch-off function for Channel 4.
6
OVP3_ON
R/W
The default value is programmed by factory fuse.
0 = disable the OVP latch-off function for Channel 3.
1 = enable the OVP latch-off function for Channel 3.
5
OVP2_ON
R/W
The default value is programmed by factory fuse.
0 = disable the OVP latch-off function for Channel 2.
1 = enable the OVP latch-off function for Channel 2.
4
OVP1_ON
R/W
The default value is programmed by factory fuse.
0 = disable the OVP latch-off function for Channel 1.
1 = enable the OVP latch-off function for Channel 1.
3
SCP4_ON
R/W
The default value is programmed by factory fuse.
0 = disable the SCP latch-off function for Channel 4.
1 = enable the SCP latch-off function for Channel 4.
2
SCP3_ON
R/W
The default value is programmed by factory fuse.
0 = disable the SCP latch-off function for Channel 3.
1 = enable the SCP latch-off function for Channel 3.
1
SCP2_ON
R/W
The default value is programmed by factory fuse.
0 = disable the SCP latch-off function for Channel 2.
1 = enable the SCP latch-off function for Channel 2.
0
SCP1_ON
R/W
The default value is programmed by factory fuse.
0 = disable the SCP latch-off function for Channel 1.
1 = enable the SCP latch-off function for Channel 1.
