Data Sheet
ADP5050
Rev. 0 | Page 47 of 60
REGISTER 8: SW_CFG (SWITCHING FREQUENCY AND PHASE SHIFT CONFIGURATION), ADDRESS 0x08
Register 8 is used to configure the switching frequency for Channel 1 and Channel 3 and to configure the phase shift for Channel 2,
Channel 3, and Channel 4 with respect to Channel 1 (0˚). The default values for the Channel 1 and Channel 3 switching frequencies
can be programmed by factory fuse.
Table 33. Register 8 Bit Assignments
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
FREQ3
FREQ1
PHASE4[1:0]
PHASE3[1:0]
PHASE2[1:0]
Table 34. SW_CFG Register, Bit Function Descriptions
Bits
Bit Name
Access
Description
7
FREQ3
R/W
The default value can be programmed by factory fuse.
0 = switching frequency for Channel 3 is the same as the master frequency set by the RT pin.
1 = switching frequency for Channel 3 is half the master frequency set by the RT pin.
6
FREQ1
R/W
The default value can be programmed by factory fuse.
0 = switching frequency for Channel 1 is the same as the master frequency set by the RT pin.
1 = switching frequency for Channel 1 is half the master frequency set by the RT pin.
[5:4]
PHASE4[1:0]
R/W
These bits configure the phase shift for Channel 4 with respect to Channel 1 (0°).
00 = 0° phase shift.
01 = 90° phase shift.
10 = 180° phase shift (default).
11 = 270° phase shift.
[3:2]
PHASE3[1:0]
R/W
These bits configure the phase shift for Channel 3 with respect to Channel 1 (0°).
00 = 0° phase shift (default).
01 = 90° phase shift.
10 = 180° phase shift.
11 = 270° phase shift.
[1:0]
PHASE2[1:0]
R/W
These bits configure the phase shift for Channel 2 with respect to Channel 1 (0°).
00 = 0° phase shift.
01 = 90° phase shift.
10 = 180° phase shift (default).
11 = 270° phase shift.
