1 / 53 page  Preliminary data This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice. October 2011 Doc ID 022405 Rev 1 1/53 53 LIS3DSH MEMS digital output motion sensor ultra low-power high performance three-axis “nano” accelerometer Features ■ Wide supply voltage, 1.71 V to 3.6 V ■ Independent IOs supply (1.8 V) and supply voltage compatible ■ Ultra low-power consumption ■ ±2g/±4g/±6g/±8g/±16g dynamically selectable full-scale ■ I2C/SPI digital output interface ■ 16-bit data output ■ Programmable embedded state machines ■ Embedded temperature sensor ■ Embedded self-test ■ Embedded FIFO ■ 10000 g high shock survivability ■ ECOPACK® RoHS and “Green” compliant Applications ■ Motion controlled user interface ■ Gaming and virtual reality ■ Pedometer ■ Intelligent power saving for handheld devices ■ Display orientation ■ Click/double click recognition ■ Impact recognition and logging ■ Vibration monitoring and compensation Description The LIS3DSH is an ultra low-power high performance three-axis linear accelerometer belonging to the “nano” family with embedded state machine that can be programmed to implement autonomous applications. The LIS3DSH has dynamically selectable full scales of ±2g/±4g/±6g/±8g/±16g and it is capable of measuring accelerations with output data rates from 3.125 Hz to 1.6 kHz. The self-test capability allows the user to check the functioning of the sensor in the final application. The device can be configured to generate interrupt signals activated by user defined motion patterns. The LIS3DSH has an integrated first in, first out (FIFO) buffer allowing the user to store data for host processor intervention reduction. The LIS3DSH is available in a small thin plastic land grid array package (LGA) and it is guaranteed to operate over an extended temperature range from -40 °C to +85 °C. Table 1. Device summary Order codes Temperature range [ ° C] Package Packaging LIS3DSH -40 to +85 LGA-16 Tray LIS3DSHTR -40 to +85 LGA-16 Tape and reel LGA-16 (3x3x1 mm) www.st.com |
