LIS3DSH
Register description
Doc ID 022405 Rev 1
45/53
8.41
OUTS1 (5Fh)
Output flags on axis for interrupt SM1 management.
Read action of this register, depending on the flag affects SM1 interrupt functions.
8.42
PEAK1 (19h)
Peak detection value register for SM1 operation.
Peak detected value for next condition SM1.
8.43
CTRL_REG2 (22h)
State program 2 interrupt MNG - SM2 control register.
Table 79.
OUTS1 register
P_X
N_X
P_Y
N_Y
P_Z
N_Z
P_V
N_V
Table 80.
OUTS1 register description
P_X
0=X + no show, 1=X+ show
N_X
0=X - no show, 1=X – show
P_Y
0=Y + no show, 1=Y + show
N_Y
0=Y - no show, 1=Y – show
P_Z
0=Z + no show, 1=Z + show
N_Z
0=Z - no show, 1=Z – show
P_V
0=V + no show, 1=V + show
N_V
0=V - no show, 1=V – show
Table 81.
PEAK1 default value
0
000
00
00
Table 82.
SM2 control register
HYST2_2
HYST1_2
HYST0_2
-
SM2_PIN
-
-
SM2_EN
