IR3447
43
www.irf.com
© 2013 International Rectifier
July 17, 2013
Figure 42e: IRDC3447 Demo board Layout Considerations – Mid Layer 3
Figure 42f: IRDC3447 Demo board Layout Considerations – Mid Layer 4
-Feedback and Vsns traces
routing should be kept away from
noise sources
PGND
Vout
PGND
Remote Sense Traces
- tap output where voltage value is
critical.
- Avoid noisy areas and noise coupling.
- RS+ and RS- lines near each other.
- Minimize trace resistance.
