AT89C51RD2 / AT89C51ED2 QualPack
Rev. 0 – 2003 July
5
3.2 Product Design
Die Size
17,9 mm
2
Pad Size Opening / Pitch
66 um * 66 um / 111 um
Logic Effective Channel Length
0.35
µm
Gate Poly Width (min.)
0.35
µm
Gate Poly Spacing (min.)
0.42
µm
Metal 1 Width
0.42
µm
Metal 1 Spacing
0.49
µm
Metal 2 Width
0.56
µm
Metal 2 Spacing
0.49
µm
Metal 3 Width
0.56
µm
Metal 3 Spacing
0.49
µm
Contact Size
0.35
µm
Contact Spacing
0.42
µm
Via 1 Size
0.42
µm
Via 2 Size
0.42
µm
