AB18X5 Real-Time Clock with Power
Management Family
Date of Issue: October 16, 2014
3.0 x 3.0 mm
Page 31 of 37
Abracon Drawing #453568
Revision: C
Table 15: Tape and Reel Dimensions
330 x 178 x 12 mm Reel Dimensions
3x3 QFN Carrier Tape Dimensions
Symbol
MIN
TYP
MAX
Units
Symbol
MIN
TYP
MAX
Units
T
2.3
2.5
2.7
mm
B0
3.2
3.3
3.4
mm
N
178.0
K0
0.9
1.0
1.1
L
330.0
K1
0.25
0.3
0.35
W1
12.4
12.4
12.6
D0
1.50
1.55
1.60
W2
18.4
D1
1.5
W3
12.4
15.4
P0
3.9
4.0
4.1
C
12.8
13.0
13.5
P1
7.9
8.0
8.1
D
20.2
P2
1.9
2.0
2.1
A
10.0
A0
3.2
3.3
3.4
G
4.0
E1
1.65
1.75
1.85
B
1.5
F
5.4
5.5
5.6
W
11.7
12.0
12.3
