SP2T PIN Diode Switch

Rev. V1

MSW200x-200

6

6

M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.

Visit www.macom.com for additional data sheets and product information.

For further information and support please visit:

https://www.macom.com/support

DS-xxxxxxx

6

Absolute Maximum Ratings

Parameter

Conditions

Absolute Maximum

Forward Current

Ant, TX or RX Port

DC Port

250 mA

150 mA

Reverse Voltage

TX or RX Port

DC Port

125 V

125 V

Forward Diode Voltage

1.2 V

TX or Ant Port

Source & Load VSWR = 1.5:1,

50 dBm

RX or Ant Port

Source & Load VSWR = 1.5:1,

43 dBm

RX or Ant Port

Pulse Width = 10 µs, Duty Cycle = 1%

57 dBm

3.5 W

Junction Temperature

—

+175°C

Operating Temperature

—

-65°C to +125°C

Storage Temperature

—

-65°C to +150°C

Assembly Temperature

t = 10 s

+260°C

Handling Procedures

Please observe the following precautions to avoid

damage:

Static Sensitivity

These

electronic

devices

are

sensitive

to

electrostatic discharge (ESD) and can be damaged

by static electricity. Proper ESD control techniques

should be used when handling these Class 1C

(HBM) devices. The moisture sensitivity level (MSL)

rating for this part is MSL 1.

Environmental Capabilities

The MSW204x-204 diode is capable of meeting the

environmental requirements of MIL-STD-202 and

MIL-STD-750.

4. Backside RF and DC grounding area of device must be completely solder attached to the RF circuit board vias for proper electrical and

thermal circuit grounding.
